| CPU | LGA1851 socket, Supports Intel® Core™ Ultra Processors, L3 cache varies by CPU. |
| Chipset | Intel® Z890 Express Chipset. |
| Memory | DDR5 support up to 9200MT/s (O.C.), 4 x DDR5 DIMM, max 256 GB, Dual Channel, ECC/Non-ECC Un-buffered DIMMs, XMP memory modules, CUDIMM support. |
| Graphics | Integrated Intel® HD Graphics, Thunderbolt 4/USB4 outputs: Max 5120x2880@60Hz, 3840x2160@240Hz, HDMI: 1920x1080@30Hz, DisplayPort: 4096x2304@60Hz. Supports up to triple displays. |
| Audio | Realtek® ALC1220 CODEC, 2/4/5.1/7.1-channel audio, S/PDIF out, DSD audio support via back panel. |
| LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps). |
| Wireless | MediaTek Wi-Fi 7 MT7925 (PCB rev. 1.0) or Realtek® Wi-Fi 7 RTL8922AE (PCB rev. 1.1), Bluetooth 5.4, 2.4/5/6 GHz bands, supports 11be 160MHz wireless standard. |
| Expansion Slots | 1 x PCIe 5.0 x16, 2 x PCIe 4.0 x4. |
| Storage Interface | 2 x M.2 (CPU), 2 x M.2 (Chipset), 4 x SATA 6Gb/s, NVMe/SATA RAID 0, 1, 5, 10 support. |
| USB Ports | Thunderbolt™ 4 (USB Type-C®), 1 x USB Type-C® (USB 3.2 Gen 2), 2 x USB 3.2 Gen 2 Type-A, 5 x USB 3.2 Gen 1, 8 x USB 2.0/1.1. |
| Internal I/O | 24-pin ATX power, 2 x 8-pin ATX 12V, 4 x M.2, 4 x SATA, RGB headers, fan headers, USB headers, TPM header. |
| Back Panel | 1 x Thunderbolt 4 (USB-C), 2 x USB 3.2 Gen 2 Type-A, 3 x USB 3.2 Gen 1, 4 x USB 2.0, 2 x antenna connectors, 1 x DisplayPort, 1 x RJ-45, 1 x S/PDIF out, 2 x audio jacks. |
| I/O Controller | iTE® I/O Controller Chip. |
| Monitoring | Voltage, Temperature, Fan speed, Water cooling flow rate, Fan fail warning, Fan speed control. |
| BIOS | AMI UEFI BIOS, 256 Mbit flash, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0. |
| Unique Features | GIGABYTE Control Center, Q-Flash, Q-Flash Plus, Smart Backup. |
| Bundled Software | Norton® Internet Security (OEM), LAN bandwidth management software. |
| Operating System | Windows 11 64-bit. |
| Form Factor | ATX, 30.5cm x 24.4cm. |
