| CPU | LGA1851 socket: Support for Intel® Core™ Ultra Processor; L3 cache varies with CPU |
| Chipset | Intel® Z890 Express Chipset |
| Memory | Support for DDR5 up to 9500(O.C); 4 x DDR5 DIMM sockets supporting up to 256 GB, Dual channel, ECC & non-ECC support |
| Onboard Graphics | Integrated Intel® HD Graphics with Thunderbolt™ 4 (USB4®) and front HDMI port |
| Audio | Realtek® ALC1220 CODEC; High Definition Audio 2/4/5.1/7.1-channel; Support for S/PDIF Out |
| LAN | Realtek® 2.5GbE LAN chip |
| Wireless Communication | MediaTek Wi-Fi 7 MT7925/ Realtek® Wi-Fi 7 RTL8922AE; Bluetooth 5.4 |
| Expansion Slots | 1 x PCIe 5.0 x16, 1 x PCIe 4.0 x4, 1 x PCIe 4.0 x1 |
| Storage Interface | 5 x M.2 connectors (PCIe 5.0/4.0/2.0), 4 x SATA 6Gb/s; RAID 0, 1, 5, 10 support |
| USB Ports | Thunderbolt™ 4, USB Type-C® (USB 3.2 Gen 2x2), USB 3.2 Gen 2, USB 3.2 Gen 1, USB 2.0 |
| Internal I/O Connectors | ATX power, CPU fan, system fan headers, RGB LED strip headers, front panel audio, HDMI, USB 3.2, USB 2.0, TPM header |
| Back Panel Connectors | USB 2.0, USB 3.2 Gen 1, Thunderbolt™ 4 (USB Type-C®), RJ-45, S/PDIF, Audio Jacks |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage, temperature, fan speed, water cooling detection, fan fail warning, noise detection |
| BIOS | 256 Mbit flash; AMI UEFI BIOS |
| Unique Features | GIGABYTE Control Center, Q-Flash, Q-Flash Plus, Smart Backup |
| Bundled Software | Norton® Internet Security (OEM version), LAN bandwidth management software |
| Operating System | Support for Windows 11 64-bit |
| Form Factor | ATX Form Factor; 30.5 cm x 24.4 cm |
